床身上大回轉直徑

Swing over bed

mm

630

橫滑板上大回轉直徑

Swing over cross slide

mm

350

大工件長度

Distance between centers

mm

1000-6000

床身導軌寬度

Guideway width

mm

550

床身承重范圍

Max. load capacity

T

3

主軸孔徑范圍

Spindle bore

mm

104

主軸孔徑錐度

Spindle bore taper

-

Metric φ120/MT5

主軸鼻端型號

Spindle nose type

-

C11

主軸轉速級數

Spindle speed steps

-

4檔變頻

VF. 3 steps

4檔液壓

HYD. 4 steps

主軸轉速范圍

Spindle speed range

rpm

10-1000

17-1000

卡盤規格

Chuck

mm

φ315手動三爪/φ315 3-jaw manual

刀架類型

Turret/tool post

-

4工位電動刀架

Eletric 4 position

刀具尺寸

Tool size

mm

32 x 32

X軸行程

X axis travel

mm

320

Z軸行程

Z axis travel

mm

850/1350/1850/2850/3850/4850/5850

X軸快速進給速度

X axis rapid traverse

mm/min

4000

Z軸快速進給速度

Z axis rapid traverse

mm/min

6000

尾座套筒直徑

Tailstock quill diameter

mm

φ100

尾座套筒錐度

Tailstock quill taper

-

MT5

尾座套筒行程

Tailstock quill travel

mm

250

主軸電機

Main spindle motor

kw

11

冷卻泵電機

Coolant pump motor

kw

0.125

機床重量

Machine weight

Weightfor 1000

kg

3700

Weightfor 1500

kg

4100

Weightfor 2000

kg

4500

Weightfor 3000

kg

5300

Weightfor 4000

kg

6100

Weightfor 5000

kg

6900

Weightfor 6000

kg

7700

外形尺寸

Overall dimension

Dimension for 1000

mm

3300x1750x1850

Dimension for 1500

mm
